Model : | ZW-T101BFHA-XX |
LCD Type | TFT |
Brand : | Xuhong |
Keywords Desc. | 10.1-inch 1920 * 1200 TFT LCD module with 1200nits ultra high brightness outdoor visibility, 45pins LVDS full view angle |
Product Class : | Graphic Display |
Product Tags : | Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD, IPS LCD |
Application : | Industrial, Outdoor High Brightness |
Panel Type : | a-Si TFT-LCD |
Panel Composition : | LCM |
Panel Size : | 10.1" |
Resolution : | 1920×1200 |
Aspect Ratio : | 16:10 (W:H) |
Form Factor : | Flat Rectangle |
Active Area : | 216.91 (W) × 135.5 (H) mm |
Outline Dimension : | 228.72 (W) × 148.36 (H) mm |
Max. Depth : | 4.51 mm |
LC Family : | IPS |
Polarizer : | Transmissive |
Brightness : | 1200nits |
Contrast Ratio : | 900:1 (Typ.) |
Viewing Angle : | 80/80/80/80 (L/R/U/D) |
Viewing Direction | Symmetry |
Backlight | WLED |
Display Colors : | 16.7M |
Interface： | LVDS |
Interface Pins : | 45Pins |
Touch Panel : | Without |
Operating Temp. : | -20 ~ 70 °C |
Storage Temp. : | -30 ~ 80 °C |
