Model : | PC043IA84-B10 |
LCD Type | TFT |
Brand : | Xuhong |
Keywords Desc. | 4.3inch800*480 TFTLCD 400nits , 40pins RGB, High temperature, Wide angle of view |
Product Class : | Graphic Display |
Product Tags : | Color TFT-LCD, Wide Temperature LCD, IPS LCD |
Application : | Handheld & PDA, Healthcare, Home Appliance, Industrial, Portable Navigation |
Panel Type : | a-Si TFT-LCD |
Panel Composition : | LCM |
Panel Size : | 4.3" |
Resolution : | 800*480 |
Aspect Ratio : | 16:9 (W:H) |
Form Factor : | Flat Rectangle |
Active Area : | 95.04 (W) × 53.86 (H) mm (A.A) |
Outline Dimension : | 105.5 (W) × 67.2 (H) mm |
Max. Depth : | 3.0mm |
Controller | ST7262E43 |
Power Supply Voltage | 3.3V |
LC Family : | IPS |
Polarizer : | Transmissive |
Brightness : | 400nits |
Contrast Ratio : | 1200:1 (Typ.) |
Viewing Angle : | 80/80/80/80 (L/R/U/D) |
Viewing Direction | ALL |
Gray scale inversion direction | ALL |
Display Colors : | 16.7M |
Backlight | 10-LED |
Interface Type : | RGB interface |
Interface Pins : | 40Pins |
Touch Panel : | Without |
Operating Temp. : | -30 ~ 85 °C |
Storage Temp. : | -30~+85°C |
