Model : | ZW-T050HMI-03 |
LCD Type | TFT |
Brand : | Xuhong |
Keywords Desc. | 5.0 inch 720x1280 TFT LCD module 350nits, 40pins RGB, IPS |
Product Class : | Graphic Display |
Product Tags : | Color TFT-LCD, Wide Temperature LCD |
Application : | Handheld & PDA, Portable Navigation |
Panel Type : | a-Si TFT-LCD |
Panel Composition : | LCM |
Panel Size : | 5.0" |
Resolution : | 720×1280 |
Controller | ILI9881C |
Aspect Ratio : | 9:16 (W:H) |
Form Factor : | Flat Rectangle |
Active Area : | 62.1 (W) × 110.4 (H) mm (A.A) |
Outline Dimension : | 64.7 (W) × 118.7 (H) mm |
Max. Depth : | 1.72 mm |
Power Supply Voltage | 2.8V |
LC Family : | IPS |
Polarizer : | Transmissive |
Brightness : | 350nits |
Contrast Ratio : | 800:1 (Typ.) |
Viewing Angle : | 80/80/80/80 (L/R/U/D) |
Viewing Direction | ALL |
Display Colors : | 16.7M |
Backlight | 6S2P-LEDs (white) |
Interface： | MIPI |
Interface Pins : | 40Pins |
Touch Panel : | Without |
Operating Temp. : | -10 ~+60 °C |
Storage Temp. : | -20~+70°C |
