Model : | XH-T055BZIA-01 |
LCD Type | TFT |
Brand : | Xuhong |
Keywords Desc. | 5.5 inch 1080 * 1920 TFT LCD module 650nits 1500:1 31pins MIPI IPS full view |
Product Class : | Graphic Display |
Product Tags : | Color TFT-LCD, Wide Temperature LCD |
Application : | Industrial |
Panel Type : | a-Si TFT-LCD |
Panel Composition : | LCM |
Panel Size : | 5.5" |
Resolution : | 1080×1920 |
Aspect Ratio : | 9:16 (W:H) |
Controller | ILI9885 |
Form Factor : | Flat Rectangle |
Active Area : | 68.04 (W) × 120.96 (H) mm (A.A) |
Outline Dimension : | 71.6 (W) × 129.57 (H) mm |
Max. Depth : | 1.95 mm |
Power Supply Voltage | 2.8V |
LC Family : | IPS |
Polarizer : | Transmissive |
Brightness : | 650nits |
Contrast Ratio : | 1500:1 (Typ.) |
Viewing Angle : | 80/80/80/80 (L/R/U/D) |
Viewing Direction | Symmetry |
Display Colors : | 16.7M |
Backlight | 14-LEDs (white) |
Interface： | MIPI |
Interface Pins : | 31Pins |
Touch Panel : | Without |
Operating Temp. : | -20 ~+ 70 °C |
Storage Temp. : | -30~+80°C |
