Model : | XH-T057BGH-01 |
LCD Type | TFT |
Brand : | Xuhong |
Keywords Desc. | 5.7inch, 640*480, 700nits, High Brightness, 40pins, TTL I/F , HX8250-A01*2+HX8678B*1, TN LCD MODULE |
Product Class : | Graphic Display |
Product Tags : | Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD |
Application : | Outdoor High Brightness |
Panel Type : | a-Si TFT-LCD |
Panel Composition : | LCM |
Panel Size : | 5.7" |
Resolution : | 640×480 |
Aspect Ratio : | 4:3 (W:H) |
Form Factor : | Flat Rectangle |
Active Area : | 115.2 (W) × 86.4 (H) mm |
Outline Dimension : | 127 (W) × 98.4 (H) mm |
Max. Depth : | 5.8 mm |
Power Supply Voltage | 3.3V |
Controller | HX8250-A01*2+HX8678B*1 |
LC Family : | TN |
Polarizer : | Transmissive |
Brightness : | 700nits |
Contrast Ratio : | 250:1 (Min.) |
Viewing Angle : | 65/65/65/55 (L/R/U/D) |
Viewing Direction | 6 o'clock |
Gray inversion Direction | 12 o'clock |
Display Colors : | 262K |
Backlight | 3S7P-LEDs (white) |
Interface： | RGB666 |
Interface Pins : | 40Pins |
Touch Panel : | Without |
Operating Temp. : | -20 ~+ 70 °C |
Storage Temp. : | -30~+80°C |
