Model : | XH-T070JWHA-04 |
LCD Type | TFT |
Brand : | Xuhong |
Keywords Desc. | 7.0-inch 800 * 480 TFT LCD module 1100nits, 40pins LVDS, IPS full angle wide temperature, high brightness, suitable for car use |
Product Class : | Graphic Display |
Product Tags : | Color TFT-LCD, Wide Temperature LCD, High Brightness LCD, Sunlight Readable LCD, IPS LCD |
Application : | Automotive Display |
Panel Type : | a-Si TFT-LCD |
Panel Composition : | LCM |
Panel Size : | 7" |
Resolution : | 800×480 |
Aspect Ratio : | 15:9 (W:H) |
Form Factor : | Flat Rectangle |
Active Area : | 152.4 (W) × 91.44 (H) mm |
Outline Dimension : | 168.26 (W) × 109 (H) mm |
Max. Depth : | 5.91mm |
LC Family : | IPS |
Polarizer : | Transmissive |
Brightness : | 1100nits |
Contrast Ratio : | 800:1 (Typ.) |
Viewing Angle : | 80/80/80/80 (L/R/U/D) |
Viewing Direction | Symmetry |
Backlight | WLED |
Display Colors : | 16.7M |
Interface： | LVDS |
Interface Pins : | 40Pins |
Touch Panel : | Without |
Operating Temp. : | -30 ~ 85 °C |
Storage Temp. : | -40 ~ 90 °C |
