| Basic Detail : | Manufacturer | AUO | Model Name | G150XTN06.7 |
| Panel Type | a-Si TFT-LCD , LCM | Model Alias | ||
| Panel Size | 15inch | Designed For | Idustrial | |
| Maximum Ratings : | OP Temperature | -30 ~ 85°C | ST Temperature | -30 ~ 85°C |
| RoHS | RoHS | Vibration Level | 1.5G (14.7 m/s²) | |
| Features : | Wide Temperature，WLED Backlight，Life>=50K hours,With LED Driver,Upside I/F, Matte | |||
| Basic Information : | Luminance | 350cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
| Good View at | - | Response Speed | 5.7/2.3 (Typ.)(Tr/Td) | |
| Viewing Angle | 80/80/70/80 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Support Color | 16.2M (6-bit + FRC) |
| Color Temperature | 6485K | White Variation | 1.25/1.33 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 60% | sRGB | 84% coverage |
| Adobe RGB | 63% coverage | DCI-P3 | 63% coverage | |
| Rec.2020 | 45% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
| Pixel Features : | Number of Pixel | 1024(RGB)×768, XGA | Arrangement | RGB Vertical Stripe | |||
| Dot Pitch(W×H) | 0.099×0.297 (H×V) | Pixel Pitch(W×H) | 0.297×0.297 (H×V) [85PPI] | ||||
| Physical Size : | Active Viewing(mm) | 304.128(H) × 228.096(V) | Outline Dim.(mm) | 326.5(H) × 253.5(V) | |||
| Bezel Area(mm) | 311.9(H) × 236.85(V) | Depth(mm) | 10.0 (Max.) | ||||
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | ||||
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | ||||
| Mounting : | Side mounting holes (4-M3) on left, right bezel | ||||||
| Other Spec : | Weight | 1.00Kgs (Typ.) | Treatment | Antiglare, Hard coating (3H) | |||
| Refresh Rate : | 60Hz |
| Reverse Scan : | No |
| Total Consumption : | 7.8W (Typ.) |
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 1.0/1.2A (Typ./Max.) | ||
| Consumption | 3.3/3.96W (Typ./Max.) | Signal Interface | eDP (1 Lane), eDP1.2 | |||
| Interface Features : | Position | Rear | Type | Connector | ||
| Interface Detail : | Brand | Model | Pitch | Pins | Quantity | Pin Configuration |
| STM | MSAK24025P30 | 0.5 mm | 30 pins | 1 pcs | EDP-30P1L-030A | |
| Lamp Features : | Lamp Type | WLED | Quantity | - | Position | Edge light type (Top side) | |||
| Exchange | No | Lamp Shape | - | Lamp Life | 50K(Min.) (Hours) | ||||
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | |||||
| Backlight Driver : | With LED Driver | ||||||||
| Driver Electrical : | Voltage Supply | 12.0±1.2V | Current Supply | 0.38/0.45A (Typ./Max.) | |||||
| Consumption | 4.5/5.0W (Typ./Max.) | ||||||||
| Package Box : | Quantity | Weight | Box Size |
| 14pcs / box | 16.5 Kgs (Max.) | 430×370×350 mm (L×W×H) |
