| Basic Detail : | Manufacturer | AUO | Model Name | G050VTN01.0 |
| Panel Type | a-Si TFT-LCD , LCM | |||
| Panel Size | 5.0inch | Designed For | Industrial | |
| Maximum Ratings : | OP Temperature | -20~ 70 °C | ST Temperature | -30 ~ 80 °C |
| RoHS | RoHS | Vibration Level | 2.0G (196 m/s²) | |
| Features : | WLED Backlight，Glossy | |||
AUO G050VTN01.0 Optical Details
| Basic Information : | Luminance | 370 cd/m² (Typ.) | Contrast Ratio | 600:1 (Typ.) (Transmissive) |
| Good View at | - | Response Speed | 20 (Typ.)(Tr+Td) | |
| Viewing Angle | 75/75/65/75 (Typ.)(CR≥10) |
Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.310; Wy:0.330 | Support Color | 16.2M (6-bit + FRC) |
| Color Temperature |
6638K | White Variation | 1.25/1.33 (Typ./Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 53% | sRGB | 75% coverage |
| Adobe RGB | 56% coverage | DCI-P3 | 55% coverage | |
| Rec.2020 | 40% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
AUO G050VTN01.0 Mechanical Details
| Pixel Features : | Number of Pixel | 480(RGB)×272, WQVGA | Arrangement | RGB Vertical Stripe |
| Dot Pitch(W×H) | 0.045×0.135 (H×V) | Pixel Pitch(W×H) | 0.135×0.135 (H×V) [188PPI] | |
| Physical Size : | Active Viewing | 108(H) × 64.8(V) | Overall Dim. | 120.7(H) × 76.3(V) |
| Bezel Opening | 111.25(H) × 68.7(V) | Overall Depth | 3.1±0.2 | |
| Aspect Ratio(W:H) | 15:9 | Shape Style | ||
| Mounting : | Without | |||
| Other Detail : | Mass | 58.0±2.0g | Treatment | Glare (Haze 0%), Hard coating (3H) |
AUO G050VTN01.0 Electronics Details
| Refresh Rate : | 60Hz |
| Reverse Scan : | No |
| Total Consumption : | TBD |
AUO G050VTN01.0 Interface Detail
| Signal Electrical : | Input Current | 75/90mA (Typ./Max.) | Input Voltage | 3.3V (Typ.) | ||
| Consumption | 0.25/0.3W (Typ./Max.) | Signal Interface | TTL (1 ch, 8-bit) | |||
| Logic Voltage : | 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD | |||||
| Interface Features : | Position |
- | Physical Type | FPC | ||
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment |
| 0.5 mm | 40 pins | 1 pcs | ||||
AUO G050VTN01.0 Backlight Details
| Lamp Features : | Lamp Type | WLED | Amount | 3S3P | Position | Edge light type |
| Exchange | - | Lamp Shape | Array | Lamp Life | 20K(Min.) (Hours) | |
| Lamp Electrical : | Input Voltage | 8.4/9.0/9.9V (Min./Typ./Max.) | Input Current | 60mA (Typ.) | ||
| Consumption | 0.5/0.54/0.59W (Min./Typ./Max.) | |||||
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
AUO G050VTN01.0 Packing Details
| Package Box : | Amount | Size (L×W×H) | Weight |
| 120 pcs / box |
13 Kgs | 520×340×250 mm (L×W×H) |
