1、BOE EV133FHM-N40 Application Details
Basic Detail : | Manufacturer | BOE | Model Name | EV133FHM-N40 |
Panel Type | a-Si TFT-LCD , LCM | Another Name | ||
Panel Size | 13.3 inch | Designed For | Medical Imaging | |
Maximum Ratings : | OP Temperature | 0 ~ 50 °C | ST Temperature | -20 ~ 60 °C |
RoHS | RoHS | Vibration Level | 1.5G (14.7 m/s²) | |
Features : | WLED Backlight，With LED Driver，Reverse I/F,Matte | |||
2、BOE EV133FHM-N40 Optical Details
Basic Detail : | Luminance | 300 cd/m² (Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
Good View at | Symmetry | Response Speed | 30 (Typ.)(Tr+Td) (ms) | |
Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Operating Mode | ADS, Normally Black, Transmissive | |
Color Performance : | Chromaticity | Wx:0.309; Wy:0.340 | Support Color | 16.7M (8-bit) |
Color Temperature | 6602K | White Variation | 1.25/1.60 (Max.)(5/13 points) | |
1931 Color Gamut : | NTSC Ratio | 72% | sRGB | 92% coverage |
Adobe RGB | 71% coverage | DCI-P3 | 75% coverage | |
Rec.2020 | 54% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
3、BOE EV133FHM-N40 Mechanical Details
Pixel Features : | Number of Pixel | 1280(RGB)×1024 [SXGA] | Arrangement | RGB Vertical Stripe |
Dot Pitch(W×H) | 0.088×0.264 mm (H×V) | Pixel Pitch(W×H) | 0.264×0.264 mm (H×V) [96PPI] | |
Physical Size : | Active Viewing | 337.92×270.336 mm (H×V) | Bezel Area | 341.9×274.4 mm (H×V) |
Outline Dim. | 358.5×296.5 mm (H×V) | Outline Depth | 10.5/11 (Typ./Max.) mm | |
Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
Aspect Ratio(W:H) | 5:4 | Shape Style | ||
Fixation : | Side mounting holes (4-M3) on left, right bezel | |||
Other Detail : | Mass | 1.26/1.40/1.47Kgs (Min./Typ./Max.) | Surface | Antiglare (Haze 25%), Hard coating (3H) |
4、BOE EV133FHM-N40 Electronics Details
Refresh Rate : | 60Hz |
Reverse Scan : | No |
Total Consumption : | 3.8W (Typ.) |
5、BOE EV133FHM-N40 Interface Details
Signal Electrical : | Input Current | 180/260/420mA (Min./Typ./Max.) | Input Voltage | 3.3V (Typ.) | ||
Consumption | 0.9W (Typ.) | Signal Interface | eDP (2 Lanes), eDP1.2, HBR1 (2.7G/lane) | |||
Interface Features : | Position | Right of Board | Type | Connect | ||
Interface Detail : | Brand | Model | Pitch | Pins | Amount | Pin Assignment |
UJU | IS050-L30B-C10 | 0.5mm | 30 pins | 1 pcs | EDP-30P2L-020A | |
6、BOE EV133FHM-N40 Backlight Details
Lamp Features : | Lamp Type | 4 strings | Amount | 9S4P | Position | Edge light type | ||
Exchange | - | Lamp Shape | WLED | Lamp Life | 15K(Min.) (Hours) | |||
Interface Features : | Position | - | Type | Connector | ||||
Backlight Driver : | With LED Driver | |||||||
Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration | ||
MASK24037P9 | 9pins | 1 pcs | BLE-9PINS-CCCCNNAAA | |||||
Driver Electrical : | Voltage Input | 12.0V (Typ.) | Current Input | - | ||||
Consumption | 2.9W (Max.) | |||||||
7、BOE EV133FHM-N40 Carton Details
Box Type | Pcs/Box | Package LWH (mm) | G.W (kgs) |
42 | 480×350×285 | 10.70 |
