1、BOE EV240WUM-N10 Application Details
Basic Detail : | Manufacturer | BOE | Model Name | EV240WUM-N10 |
Panel Type | a-Si TFT-LCD , LCM | |||
Panel Size | 24.0 inch | Designed For | Medical Imaging | |
Maximum Ratings : | OP Temperature | 0 ~ 50 °C | ST Temperature | -20 ~ 60 °C |
RoHS | RoHS | Vibration Level | 1.5G (14.7 m/s²) | |
Features : | Hight Brightness，WLED Backlight，Life≥50k hours，Upside I/F,Matte | |||
2、BOE EV240WUM-N10 Mechanical Details
Pixel Features : | Number of Pixel | 1920(RGB)×1200, WUXGA | Arrangement | RGB Vertical Stripe |
Dot Pitch(W×H) | 0.090×0.270 mm | Pixel Pitch(W×H) | 0.270×0.270 mm [94PPI] | |
Physical Size : | Active Viewing | 518.4(W)×324(H) mm | Overall Dim. | 546.4(W)×352(H) mm |
Bezel Opening | 522(W)×328(H) mm | Overall Depth | 8.9/11.7 (Typ./Max.) mm | |
Outline Features : | Form Shape | Flat Rectangle | Orientation | Landscape type |
Aspect Ratio(W:H) | 16:10 | Shape Style | ||
Fixation : | Side mounting holes (4-M3) on left, right bezel | |||
Other Detail : | Mass | 2.61Kgs (Typ.) | Surface | Antiglare (Haze 25%), Hard coating (3H) |
3、BOE EV240WUM-N10 Optical Details
Basic Information : | Luminance | 600 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
Good View at | Symmetry | Response Speed | 14 (Typ.)(G to G) ms | |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Operating Mode | ADS, Normally Black, Transmissive | |
Color Performance : | Chromaticity | Wx:0.300; Wy:0.315 | Support Color | 16.7M (8-bit) |
Color Temperature | 7435K | White Variation | 1.25/1.33 (Typ./Max.)(9 points) |
4、BOE EV240WUM-N10 Electronics Details
Refresh Rate : | 60Hz |
Reverse Scan : | No |
5、BOE EV240WUM-N10 Interface Details
Signal Electrical : | Input Current | 1.3/2.0A (Typ./Max.) | Input Voltage | 5.0V (Typ.) | ||
Consumption | 6.5/11W (Typ./Max.) | Signal Interface | LVDS (2 ch, 8-bit) | |||
Interface Features : | Position | Upper middle of panel | Physical Type | Connector | ||
Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment |
UJU | IS100-L30O-C23 | 1.0 mm | 30 pins | 1 pcs | ||
6、BOE EV240WUM-N10 Lightting Details
Lamp Features : | Lamp Type | WLED | Amount | 13S3P | Position | Edge light type (Right side) |
Exchange | - | Lamp Shape | 3 strings | Lamp Life | 50K(Min.) (Hours) | |
Lamp Electrical : | Input Voltage | 78/81.9/85.8V (Min./Typ./Max.) | Input Current | 80mA (Typ.) | ||
Consumption | 19.5/23W (Typ./Max.) | |||||
Interface Features : | Position | Down left corner | Physical Type | Connector | ||
Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment |
E&T | 3707K-S06N-01L | 1.0 mm | 6 pins | 1 pcs | BLE-6PINS-CNAACC | |
Backlight Driver : | No | |||||
7、BOE EV240WUM-N10 Packing Details
Box/Package | Pcs/Package | Package LWH (mm) | G.W (kgs) |
8 | 656×304×444 | N/A |
