Chimei Innolux G104ACJ-L01 Application Details
| Basic Detail : | Panel Brand | INNOLUX/CHI MEI | Model Name | G104ACJ-L01 |
| Panel Type | a-Si TFT-LCD , LCM | Another Name | ||
| Panel Size | 10.4” | Designed For | Industrial,Outdoor High Brightness | |
| Maximum Ratings : | OP Temperature | -40 ~ 85 °C | ST Temperature | -40 ~ 90 °C |
| RoHS | RoHS | Vibration Level | 1.5G (14.7 m/s²) | |
| Features : | Portrait type,Wide Temperature，Hight Brightness,WLED Backlight，Life>=50K hours, Matte | |||
Chimei Innolux G104ACJ-L01 Optical Details
| Basic Information : | Luminance | 900 cd/m²(Typ.) | Contrast Ratio | 1000 : 1 (Typ.) (Transmissive) |
| Good View at | Symmetry | Response Speed | 13/12 (Typ.)(Tr/Td) (ms) | |
| Viewing Angle | 85/85/85/85(Typ.)(CR≥10) | Operating Mode | AAS, Normally Black, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Display Colors | 16.7M (8-bit) |
Color Temperature | 6485K | White Variation | 1.42 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 73% | sRGB | 93% coverage |
| Adobe RGB | 72% coverage | DCI-P3 | 75% coverage | |
| Rec.2020 | 54% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
Chimei Innolux G104ACJ-L01 Mechanical Details
| Pixel Features : | Number of Pixel | 960(RGB)*1280, Quad-VGA | Arrangement | RGB Vertical Stripe |
| Dot Pitch (W×H) | 0.055*0.165 mm | Pixel Pitch (W×H) | 0.165*0.165 mm [153PPI] | |
| Physical Size : | Active Viewing(mm) | 158.4(W)*211.2(H) mm | Bezel Area (mm) | 160.6(W)*213.9(H) mm |
| Outline Dim.(mm) | 173.4(W)*228.7(H) mm | Depth(mm) | 8/14.27 (Typ./Max.) mm | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 3:4(W:H) | Orientation | Portrait type | |
| Fixation : | Rear mounting Pole (6-M2.5) | |||
| Other Spec : | Weight | 450/470g (Typ./Max.) | Surface | Antiglare, Hard coating (3H) |
Chimei Innolux G104ACJ-L01 Electronics Details
| Refresh Rate : | 60Hz |
| Reverse Scan : | No |
| Total Consumption : | 9.64W (Typ.) |
Chimei Innolux G104ACJ-L01 Interface Details
| Signal Systerm : | LVDS (1 ch, 8-bit) | Logic Voltage | - | ||||||||
| Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | 400/480mA (Typ./Max.) | |||||||
| Consumption | 1.32/1.58W (Typ./Max.) | ||||||||||
| Interface Features : | Position | - | Physical Type | Connector | |||||||
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment | |||||
| HRS | FH52-50S-0.5SH | 0.5mm | 50pins | 1 pcs | |||||||
Chimei Innolux G104ACJ-L01 Backlight Details
| Lamp Features : | Lamp Type | WLED | Quantity | - | Position | Edge light type | ||||
| Exchange | - | Lamp Shape | - | Lamp Life | 50K(Min.) (Hours) | |||||
| Lamp Electrical : | Input Voltage | 26.5/29.2/32.9V (Min./Typ./Max.) | Input Current | 95/100mA (Typ./Max.) | ||||||
| Consumption | 8.32/9.38W (Typ./Max.) | |||||||||
| Interface Features : | Position | - | Physical Type | Connector | ||||||
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment | ||||
| HRS | FH52-10S-0.5SH | 0.5 mm | 10 pins | 1 pcs | ||||||
| Backlight Driver : | No | |||||||||
Chimei Innolux G104ACJ-L01 Carton Details
| Package Box : | Amount | Weight | Size (L*W*H) |
| 18pcs / box | 10.1 Kgs | 490*350*320 mm |
