1、Innolux G121ICE-LH1 Application Details
Basic Info : | Panel Brand | INNOLUX | Panel Model | G121ICE-LH1 |
Diagonal Size | 12.1" | Application | Industrial，Outdoor High Brightness | |
Panel Type | a-Si TFT-LCD , LCM | |||
Reliability : | Operating Temp. | -30 ~ 85 °C | Storage Temp. | -30 ~ 85 °C |
RoHS State | RoHS | Vibration Rating | 1.5G (14.7 m/s²) | |
Specific Features : | Wide Temperature，Ultra High Brightness，WLED Backlight，Life≥50K hours，With LED Driver， 180°Reverse，6/8bit ，Matte | |||
2、Innolux G121ICE-LH1 Mechanical Details
Pixel Features : | Pixel Format | 1280(RGB)×800, WXGA | Dot Pitch | 0.068×0.204 mm (H×V) |
Configuration | RGB Vertical Stripe | Pixel Pitch | 0.204×0.204 mm (H×V) [124PPI] | |
Mechanical Size : | Display Area | 261.12×163.2 mm (H×V) | Outline Dim. | 264.12×166.2 mm (H×V) |
Outline Dim. | 278×184 mm (H×V) | Outline Depth | 7.1/10.5 (Typ./Max.) mm | |
Outline Features : | Form Factor | Flat Rectangle | Orientation | Landscape type |
Aspect Ratio | 16:10 (H:V) | Shape Style | ||
Holes & Brackets : | Side mounting holes (4-M2) on left, right bezel | |||
Other Features : | Weight | 470/490g (Typ./Max.) | Surface | Antiglare, Hard coating (3H) |
3、Innolux G121ICE-LH1 Optical Details
Basic Information : | Brightness | 1000 cd/m² (Typ.) | Contrast Ratio | 1000:1 (Typ.) (Transmissive) |
Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) | Optical Mode | AAS, Normally Black, Transmissive | |
Viewing Direction | Symmetry | Response Time | 12/8 (Typ.)(Tr/Td) ms | |
Color Performance : | Chromaticity | Wx:0.313; Wy:0.329 | Color Numbers | 262K/16.7M (6-bit / 8-bit) |
Color Temperature | 6485K | Uniformity | 1.25/1.43 (Typ./Max.)(5points) | |
1931 Color Gamut : | NTSC Ratio | 72% | sRGB | 94% coverage |
Adobe RGB | 73% coverage | DCI-P3 | 75% coverage | |
Rec.2020 | 54% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmittance | - |
4、Innolux G121ICE-LH1 Electronics Details
Frame Frequency : | 60Hz |
Reverse Scan : | Yes (180°) |
Power Consumption : | 11.45W (Typ.) |
5、Innolux G121ICE-LH1 Backlight Details
Back-light Features : | Lamp Type | WLED | Amount | - | Life Time | 50K(Min.) (Hours) |
Replacement | - | Lamp Shape | - | Position | Edge light type | |
Interface Features : | Type | Included in signal interface | Position | - | Lamp Driver | With LED Driver |
Driver Electrical : | Voltage Input | 12.0±1.2V | Current Input | 0.8/1.0A (Typ./Max.) | ||
Consumption | 9.6/12W (Typ./Max.) | |||||
6、Innolux G121ICE-LH1 Interface Detail
Signal Systerm : | LVDS (1 ch, 6/8-bit) | Logic Voltage | - | |||||||||||
Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | 560/675mA (Typ./Max.) | ||||||||||
Interface Features : | Type | Connector | Position | - | ||||||||||
Connector Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration | ||||||||
P-TWO | 187114-30091 | 1.0mm | 30 pins | 1 pcs | ||||||||||
7、Innolux G121ICE-LH1 Carton Details
Box Type | Pcs/Box | Package LWH (mm) | G.W (kgs) |
18 | 465×362×314 | 10.15 |
