TIANMA TM035PDHG03 Application Details
| Basic Detail : | Panel Brand | TIANMA | Model Name | TM035PDHG03 |
| Panel Type | a-Si TFT-LCD , LCM | Another Name | ||
| Panel Size | 3.5” | Designed For | Mobile Phone, Handheld&PDA | |
| Maximum Ratings : | OP Temperature | -20 ~ 70 °C | ST Temperature | -30 ~ 80 °C |
| RoHS | RoHS | Vibration Level | ||
| Features : | Portrait type, WLED Backlight | |||
TIANMA TM035PDHG03 Optical Details
| Basic Information : | Luminance | 300 cd/m² (Typ.) | Contrast Ratio | 500:1 (Typ.) (Transmissive) |
| Good View at | 6 o'clock | Response Speed | 25 (Typ.)(Tr+Td) ms | |
| Viewing Angle | 70/70/70/60 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.286; Wy:0.304 | Display Colors | 65K/262K |
| Color Temperature | 8774K | White Variation | 1.25 (Typ.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 61% | sRGB | 83% coverage |
| Adobe RGB | 64% coverage | DCI-P3 | 64% coverage | |
| Rec.2020 | 46% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) |
TIANMA TM035PDHG03 Mechanical Details
| Pixel Features : | Number of Pixel | 320(RGB)×480, HVGA | Arrangement | RGB Vertical Stripe |
| Dot Pitch (W×H) | 0.051×0.153 mm | Pixel Pitch (W×H) | 0.153×0.153 mm [166PPI] | |
| Physical Size : | Active Viewing(mm) | 48.96(W)×73.44(H) mm | Bezel Area (mm) | 49.96(W)×74.44(H) mm |
| Outline Dim.(mm) | 55.26(W)×84.69(H) mm | Depth(mm) | 2.2±0.1 mm | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 2:3 (H:V) | Orientation | Portrait type | |
| Other Spec : | Weight | 21.0g (Typ.) | Surface | Hard coating |
TIANMA TM035PDHG03 Electronics Details
| Refresh Rate : | 60Hz |
| Reverse Scan : | No |
| Driver IC : | Built-in ILI9488 |
TIANMA TM035PDHG03 Interface Details
| Signal Systerm : | CPU/RGB/SPI | Logic Voltage | 0≤VIL≤0.3IOVCC; 0.7IOVCC≤VIL≤IOVCC | ||||||||
| Signal Electrical : | Voltage Input | 1.8/2.8V (Typ.)(IOVCC/VCI) | Current Input | 34.2mW (Typ.) | |||||||
| Consumption | - | ||||||||||
| Interface Features : | Position | - | Physical Type | FPC | |||||||
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment | |||||
| 0.3mm | 45pins | 1 pcs | |||||||||
TIANMA TM035PDHG03 Backlight Details
| Lamp Features : | Lamp Type | WLED | Quantity | 1S6P | Position | Edge light type |
| Exchange | - | Lamp Shape | Lamp Life | 30K(Typ.) (Hours) | ||
| Lamp Electrical : | Input Voltage | 3.2V (Typ.) | Input Current | 20mA (Typ.) | ||
| Consumption | 384mW (Typ.) | |||||
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
TIANMA TM035PDHG03 Carton Details
| Package Box : | Amount | Weight | Size (L×W×H) |
| 324 pcs / box | 12.45±0.62 Kgs | 544×365×250 mm |
