TIANMA TM043NDHG11 Application Details
| Basic Detail : | Panel Brand | TIANMA | Model Name | TM043NDHG11 |
| Panel Type | a-Si TFT-LCD , LCM | Another Name | ||
| Panel Size | 4.3” | Designed For | Handheld&PDA,Automotive Display | |
| Maximum Ratings : | OP Temperature | -20 ~ 70 °C | ST Temperature | -30 ~ 80°C |
| RoHS | RoHS | Vibration Level | ||
| Features : | Hight Brightness，WLED Backlight,Matte | |||
TIANMA TM043NDHG11 Optical Details
| Basic Information : | Luminance | 880 cd/m²(Typ.) | Contrast Ratio | 800:1 (Typ.) (Transmissive) |
| Good View at | 6 o'clock | Response Speed | 25 (Typ.)(Tr+Td) ms | |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | Operating Mode | TN, Normally White, Transmissive | |
| Color Performance : | Chromaticity | Wx:0.307; Wy:0.330 | Display Colors | 16.7M (8-bit) |
| Color Temperature | 6802K | White Variation | 1.25 (Typ.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 51% | sRGB | 71% coverage |
| Adobe RGB | 54% coverage | DCI-P3 | 53% coverage | |
| Rec.2020 | 38% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
TIANMA TM043NDHG11 Mechanical Details
| Pixel Features : | Number of Pixel | 480(RGB)*272, WQVGA | Arrangement | RGB Vertical Stripe |
| Dot Pitch (W*H) | 0.066*0.198 mm | Pixel Pitch (W*H) | 0.198*0.198mm [128PPI] | |
| Physical Size : | Active Viewing(mm) | 95.04(H) *53.856(V) | Bezel Area (mm) | 99.04(H) *54.86(V) |
| Outline Dim.(mm) | 105.5(H) * 67.2(V) | Depth(mm) | 2.9±0.3 mm | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 16:9 (H:V) | Orientation | Landscape type | |
| Other Spec : | Weight | TBD | Surface | Antiglare, Hard coating (3H) |
TIANMA TM043NDHG11 Electronics Details
| Refresh Rate : | 60Hz |
| Reverse Scan : | No |
| Driver IC : | COG Built-in ST8272T |
| Time Controller (T-CON)： | Embedded T-CON |
TIANMA TM043NDHG11 Interface Details
| Signal Systerm : | Parallel RGB (1 ch, 8-bit) | Logic Voltage | 0≤VIL≤0.3VDD; 0.7VDD≤VIH≤VDD | ||||||||
| Signal Electrical : | Voltage Input | 3.3V (Typ.) | Current Input | TBD | |||||||
| Interface Features : | Position | - | Physical Type | FPC | |||||||
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Pin Assignment | |||||
| 0.5mm | 40pins | 1 pcs | |||||||||
TIANMA TM043NDHG11 Backlight Details
| Lamp Features : | Lamp Type | WLED | Quantity | 8S2P | Position | Edge light type |
| Exchange | - | Lamp Shape | Array | Lamp Life | 20K(Typ.) (Hours) | |
| Lamp Electrical : | Input Voltage | 25.6V (Typ.) | Input Current | 40mA (Typ.) | ||
| Consumption | 1.24W (Typ.) | |||||
| Interface Features : | Position | - | Physical Type | Included in panel signal interface | ||
| Backlight Driver : | No | |||||
TIANMA TM043NDHG11 Carton Details
| Package Box : | Amount | Weight | Size (L*W*H) |
| 112 pcs / box | TBD | 530*350*250 mm |
