The special display for endoscopic surgery uses ultra-high definition TFT LCD panel with accurate color reproduction, rich color gradation, smooth dynamic image display, and wider visual range, which meets the demand of today's rapid change medical display, and surgical site can be clearly and accurately observed. The waterproof, antibacterial treatment, electromagnetic compatibility, and a variety of video input and output interfaces make the product fully meet the requirements of various endoscopy or operating room, ICU display.
PRODUCT FEATURES:
1. Accurate color reproduction
The professional displays in the endoscopic operating room all use 14BIT technology, which can linearly display more than 4.398 trillion colors, so as to accurately restore the color of human tissues in minimally invasive surgery, so that the doctor can make a more accurate judgment.
2. rich color gradation,
Endoscopy operating room professional display uses the highest level of medical professional LCD panel with good color, high brightness and high contrast ratio, so that the gradation of each tissue during surgical procedure is distinct, and clinical operation image is clear and transparent.
3.Smooth dynamic images
The response time of Endoscopy operating room professional display is less than 18ms, so that the surgical images can be smoothly presented from standard definition to ultra-high definition, and the bleeding status and other fine operations during the surgical procedure can be clearly displayed without motion-blur and jitter.
4.Compliance with the operating room purification and anti-interference
Endoscopy operating room professional display uses the design of optical-bonding and dust-free to conform to the purification requirements of surgical equipment in the operating room. Fully enclosed design can effectively prevent dust and the liquid pollution of operation process. The metal shell body and the built-in shielding circuit can effectively prevent the interference of high-frequency electric knife and other electronic surgical equipment to the monitor, then ensure the stability of the surgical procedure display.
5.A variety of interface type
Endoscopy operating room professional display can be compatible with a variety of analog and digital signals, and can be fully matched with the camera systems of major rigid and soft lens manufacturers in the world, fully meeting the needs of a variety of brands and equipment.
Specification:
Model | E320A |
Backlight | LED |
Diagonal Dimension | 708.48(H) x 398.52(V) mm |
Resolution | 3840x2160 |
Dot Pitch | 0.1845 (H)*0.1845(V)mm |
Response Time (typ) | 18ms |
Highest Brightness (typ) | 800cd/m² |
Contrast Ratio（typ） | 1350：1 |
Color Depth（LUT） | 4398 Trillion Colors(14bit) |
Viewing Angle | 178° |
Lookup Table | GAMMA2.0,GAMMA2.2,GAMMA2.4,GAMMA2.6,DICOM |
Video Input | DVI×1; DP1.2×1; HDMI2.0×1; HDMI1.4×1; 3G-SDI×3，12G-SDIx1 |
Video Output | DVI x 1;3G-SDIx3;12G-SDIx1. |
Optional | N/A |
Power Output | DC 5V 1A x 2（DC005） |
Power Requirement | 100~240V AC, 50/60Hz |
MAX Power | 200W |
Box Color | White |
Outline size with monitor base | 758.7*260.9*(570.95-630.95)mm |
Outline size without base | 758.7*72.68*468.2 |
NET.W | 23.4 |
NET.W(without base) | 11.9 |
Installation standards | VESA standards：100*100mm，100*200mm" |
Certification and Standards | CCC、CE、energy conservation |
Menu Language | Chinese, English |
